10.4 inch android industrial touch panel pc
OVERVIEW
Advanvision industrial Fanless android Panel PCs is available in screen sizes from 6.5" up to 75". These industrial android computers run on Rackchip RK series, with RK3288, RK3568, RK3399 optional. Those android industrial panel PCs can operate Linux or Android. These operating systems are perfect for web based applications and can be easily integrated into industrial manufacturing applications. Android touch panel PCs provides a cost effective alternative to traditional Windows based panel PCs. Advanvision fanless android touch panel PCs has rugged metal enclosures and with IP65 front, flat bezel design, zero bezel design optional. They allow for durability and reliability in any environment. The android all in one touch computers solution are perfect for applications such as automated industry, building automation, smart city, and IoT cloud based solutions.
FEATURES
1, Support android 5.1, 6.0, 7.1, 9.0, 10.0,11 and Linux, Ubuntu, which are ideal platforms for running your own applications or customizing the OS for your needs.
2, With onboard DDR3 2GB-8G ram memory and 8G-64G onboard flash rom optional.
3, 10.4" industrial grade LCD panel with 800*600 or 1024*768 resolution and 1000nits high brightness optional, and available with 10point PCAP touch or resistive touch.
4, Simple and smart design with rugged metal enclosure, which have fanless cooling systems and durability in high shock and vibration settings.
5, Customized multiple I/O port to meet customers requirement, can be with SIM card slot, and support 3G/4G optional, 2 RJ45/ 3 COM RS232/RS422/RS485 optional.
6, Provide SDK, support secondary development.
7, High performance industrial android motherboard, 7x24 continuous operation.
8, Wide temperature range: operating: -20 to 70°C, storage: -30 to 80°C.
9, Phoenix terminal 9-36V wide voltage input optional.
SPECIFICATION
PC | |
CPU | ARM Quad Core RK3288 Cortex-A17, Main CPU frequency:1.8GHz |
CPU Optional | RK3399, RK3368 Optional |
GPU | Mali-T764 GPU |
SDRAM | 2G (4G, 8G optional) |
Flash | 8G: 16G/32G/64G/128G Optional |
Bluetooth | Optional |
Video Decoder | 4K VP8 and 4K 10bits H265/H264 1080P other video decoders (VC-1, MPEG-1/2/4, VP8) |
Media Format | Supports RMVB,FLV,MPEG1/2/4,AVI,WMV,MOV,MP4,TS,etc |
Music Format | Support MP3/AAC/WAV/WMA/Dolby True HD/DTS-HD/LPCM /H264/VP8/MVC
|
Network Support | Ethernet,Wifi/bluetooth 4.0,wireless peripherals,etc |
I/O Interface | 1 × HDMI; 2 × USB Max. 6× USB; 1 × TF Card Support 8~128GB; 1 × DC 12V 2.0; 3G/4G Optional; 1 × RJ45 LAN Ethernet 10/100/1000M (Realtek RTL8211E); Com Port optional |
Operation System | Android 6.0/7.1/8.0 |
LCD Panel | |
Panel size | 10.4” |
Native Resolution | 800*600 with 1024*768 optional |
Aspect ratio | 4:3 |
Brightness | 300 nits |
LED Life Time | ≥50K hours |
Contrast Ratio (Center of screen) | 700:1 |
Response Time | 20ms |
Viewing Angle | 80°/80°/60°/80° (R/L/U/D) |
Support Color | 16.7M colors |
Touch | |
Touchscreen Type | Project Capacitive Touch (10 points) |
Surface Hardness | 3H |
Luminousness | 90% |
Touch Interface | USB (RS232 optional) |
Touch Response Time | 2ms |
Working Life | >50 million times |
Touch Options | (5 wires restive touch,IR touch optional) |
Power Supply | |
External Power Supply | AC 100 - 240V , 50-60Hz |
Working Voltage | DC 12V |
Power Consumption | ≤18W |
Enclosure | |
Material | High strength cold rolled steel back case |
Color | Black, white, Silver , color can be customized |
VESA Mounting | 75×75mm/100×100mm |
IP Grade | No |
Operating Environment | |
Temperature Range | operating: -20 to 70°C, storage: -30 to 80°C |
Relative Humidity | 5%~95% @ 40° C, non-condensing |
Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
Packing Details | |
Net Weight | 3.2kg(Approx.) |
Gross Weight | 3.8kg(Approx.) |
Accessories | Power adapter, embedded screws, user manual, warranty card |
Other | |
Mounting | Vesa mounting |
wall mounting brackets (optional) | |
desk stand holder (optional) | |
Warranty | 1 year warranty |
Certificates | CE, FCC, RoHS |
Order Information | |
10.4 inch chassis android panel pc with no touch, J1900/ADV104CMAPCNTJ1 | |
10.4 inch chassis android panel pc with tempered glass,1900 /ADV104CMAPCTGJ1 | |
10.4 inch chassis android panel pc with resistive touch,J1900/ADV104CMAPCRTJ1 | |
10.4 inch chassis android panel pc with capacitive touch,J1900/ADV104CMAPCCTJ1 | |
10.4 inch chassis android panel pc with no touch, i3/ADV104CMAPCNT01I3 | |
10.4 inch chassis android panel pc with tempered glass,i3 /ADV104CMAPCTGI3 | |
10.4 inch chassis android panel pc with resistive touch,i3/ADV104CMAPCRTI3 | |
10.4 inch chassis android panel pc with capacitive touch,i3/ADV104CMAPCCTI3 | |
10.4 inch chassis android panel pc with no touch, i5/ADV104CMAPCNTI5 | |
10.4 inch chassis android panel pc with tempered glass,i5/ADV104CMAPCTGI5 | |
10.4 inch chassis android panel pc with resistive touch,i5/ADV104CMAPCRTI5 | |
10.4 inch chassis android panel pc with capacitive touch,i5/ADV104CMAPCCTI5 | |
10.4 inch chassis android panel pc with no touch, i7/ADV104CMAPCNTI7 | |
10.4 inch chassis android panel pc with tempered glass,i7/ADV104CMAPCTGI7 | |
10.4 inch chassis android panel pc with resistive touch,i7/ADV104CMAPCRTI7 | |
10.4 inch chassis android panel pc with capacitive touch,i7/ADV104CMAPCCTI7 | |
